SilverStone Raven SST-RVZ03B

  • art/SilverStone-Raven-SST-RVZ03B.jpg
  • art/SilverStone-Raven-SST-RVZ03B-3.jpg

SilverStone Raven SST-RVZ03B

Caja HTPC Slim, formato horizontal/vertical, placas Mini-ITX, fuentes ATX, 2xUSB 3.0, LED RGB

Consulta o reserva

EAN/GTIN-13: 4710007224939

Fabricante: SilverStone
Garantía: 2 años

Pulsa para mas detalle en web del fabricante

Información resumida de la marca para SilverStone Raven SST-RVZ03B:

RVZ03 Introduction

SilverStone RVZ03 is a further evolution of the highly rated RAVEN Z RVZ01-E, a slim form factor case with tremendous capability. It has the same optimized interior that has room for a standard ATX (PS2) power supply and support for some the biggest consumer graphics cards on the market with superb air cooling performance. Designed for use in either vertical or horizontal orientation, it can be placed comfortably in any space-constrained environment that requires a powerful PC. For those looking to build a slim form factor PC with extra flair, the RVZ03’s inclusion of RGB lighting and control box bring about another exciting chapter to the famed RAVEN series of computer cases.

  • Signature RAVEN styled front panel adorned with brilliant RGB light strip
  • Includes SilverStone’s easy-to-use custom RGB light strip control box, the LSB01
  • Mini-ITX motherboard & ATX PSU compatible for wide array of building possibilities
  • Support cards up to 13 inches (330mm) to fit most high-end GPUs for compute power far exceeding consoles
  • Maximum performance in slim form factor with support for AIO liquid cooling
  • Positive air pressure design for excellent cooling/quietness and dust-prevention
  • Fits in nearly any environment with horizontal or vertical orientation


RVZ03 Specifications
Model No.
SST-RVZ03B (black)
SST-RVZ03W (white)
Reinforced plastic outer shell, steel body
Drive bay
2.5" x 4*
Cooling system
1 x 120mm fan, 1500rpm, 18dBA
1 x 120mm fan, 1500rpm, 18dBA
1 x 120mm fan slot
Expansion slot
Front I/O port
USB 3.0 x 2
audio x 1
MIC x 1
Power supply
Optional PS2(ATX)
Expansion card
Compatible up to 13" (330mm) long, width restriction-5.88" (149mm)
Limitation of CPU cooler
Limitation of PSU
Net weight
4.05 kg
382mm (W) x 105mm (H) x 350mm (D), 14 Liters
15.04" (W) x 4.13" (H) x 13.78" (D), 14 Liters
Support Kensington lock
PCI Express riser card set x 1
RGB light strip control box x 1
* 2.5" drive on center bracket may be difficult or impossible to install due to power supply cable interference, we recommend using 140mm deep or shorter modular power supply with flat cables
** Maximum length for power supply is 150mm but we recommend 140mm deep power supply due to varying connector locations and the unique structure of RVZ03.Due to the use of internal power cord extension, we recommend not to exceed 800W when powering off a 110V outlet (no limit for 220V)

Single color mode:OFF > white > red > blue > green > light green > light blue > purple > single color breathing
Single color breathing mode:white > red > blue > green > light green > light blue > purple > gradient mode
Gradient mode:breathing gradient > color gradient > OFF
Sequence:OFF > single color mode > single color breathing mode > gradient mode > OFF
Press for 3 sec to turn off light at any time, lightly press again to resume operation mode prior to turn off.
